Product Page Eclipse
- Ratio 1:1
- Maximum GPM (LPM): 52 (197)
- Displacement Gallons Per Cycle (Liters): 0.232 (.88)
- Air Inlet: 1/4 - 18 N.P.T.
- Fluid Inlet: 1 - 11-1/2 N.P.T.F.,
Rp1(1-11 BSP) - Fluid Outlet: 1 - 11-1/2 N.P.T.F.,
Rp1(1-11 BSP) - Maximum Operating Pressure PSI (bar): 120 (8.3)
- Suspended Solids Maximum DIA IN. (mm): 1/8" (3.2)
- Weight - LBS. (Kg): 18.3 (8.3) PX10R-XAX-XXX
38.2 (17.3) PX10R-XSX-XXX
35.2 (16.0) PX10R-XCX-XXX
add 6.1-lbs. (2.75-kg) for Aluminum Air Motor
add 12.9-lbs. (5.84-kg) for Stainless Steel Air Motor - Maximum Dry Suction Lift: 19 Ft. (5.7) Elastomer fitted
OPERATION & MAINTENANCE MANUALS
PD10 & PE10 O, I & M Manual
SALES & ENGINEERING DATA SHEETSPD10 & PE10 Data Sheet
CHEMICAL COMPATIBILITY GUIDECHEMICAL COMPATIBILITY
EXP DIAPHRAGM PUMP SPECIFICATIONEXP DIAPHRAGM PUMP SPEC.
Features
- Available in 316LSS or Alloy C for chemical resistance
- Magnetically driven, eliminating the need for costly mechanical seals
- Patented renewable housing liner reduces repair costs
- One-piece gear and shaft assembly eliminates common gear failures at the keyway
- Designed for easy maintenance
- Zero Leakage
- Sealless design
- Zero emissions of hazardous or regulated chemicals
- Built for the harshest environments Ideal fit for many medium to highly corrosive liquids
- Fully encapsulated magnets
- Superior chemical resistance
- Ease of maintenance
- Front pull-out design
- Quick and easy service
- Piping and electrical stay in place
- Reduced downtime
- More production KOPkit® (Keep on Pumping kit) saves time and money
- Simplified orders and inventory
